Pushbutton Switch Momentary Pushbutton Switch Silver Contacts 1NO 1NC 22mm 10A Suitable for Industrial Automation and Control Panels (Blue Button (self-Reset))
4.3 (38 items)
Limited Time Sale$8.99 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 236843293 | Release Date | 2026/07/10 | List Price | $6.00 | Model Number | 236843293 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- SILVER CONTACTS This push button switch adopts premium silver contacts, which support high current load, deliver superior electrical conductivity and stable performance. It features great aging resistance and long service life, perfectly for frequent use as momentary switch and machine switch in industrial control systems.
- FLAME-RETARDANT HOUSING Constructed with high-temperature flame-retardant plastic, this safety switch owns excellent impact resistance and strong insulation. The durable structure adapts to harsh industrial environments, protecting control panel and electrical equipment for long-term steady operation.
- HIGH-QUALITY AND DURABLE Equipped with sturdy aluminum alloy button caps that are impact-resistant and oxidation-resistant for extended service life. The built-in dust-proof and sealed design blocks dust effectively, lowers internal friction and greatly improves reliability for daily industrial use.
- WIDE RANGE OF APPLICATIONS This non-latching momentary push-button switch comes with 1 normally open (NO) and 1 normally closed (NC) contact. It works well for start, stop and momentary control, widely used as start stop button, power button and reset button. Available in red, yellow, blue and green, you can match colors freely for different functional layouts.
- UNIVERSAL MOUNTING Designed with standard 22mm mounting holes, this button switch fits most industrial control cabinets, distribution boxes and button boxes. Rated up to 10A current, it enables quick and easy installation and fully meets the demands of standard industrial electrical controls.
| UPC | 780745849354 |
|---|---|
| ASIN | B0H14HQHWV |
| Color | Blue button (self-reset) |
| Terminal | Screw |
| Brand Name | JCNEtrwgy |
| Unit Count | 1.0 Count |
| Part Number | LA38 |
| Switch Type | Push Button |
| Circuit Type | 1-way |
| Contact Type | 1 Normally Open (No) and 1 Normally Closed (Nc) |
| Manufacturer | JCNEtrwgy |
| Material Type | Button cap material: Aluminum alloy, Contact material: Silver contacts, Housing material: High-temperature flame-retardant plastic |
| Mounting Type | Panel Mount |
| Connector Type | Crimp |
| Current Rating | 10 Amps |
| Operation Mode | Self-resetting/Self-locking |
| Item Dimensions | 2.6 x 1.14 x 1.26 inches |
| Number of Items | 1 |
| Contact Material | Silver |
| Operating Voltage | 500 Volts |
| Specification Met | CCC, IP54 |
| Included Components | Pushbutton Switch Head, Contact Block (1no 1nc) |
| Number of Positions | 2 |
| Upper Temperature Rating | 65 Degrees Celsius |
| International Protection Rating | IP54 |
