Ohm Meters 4105B high accuracy digital earth resistance tester AC voltage 750V power dissipation less than 800mw meter(RUOSHUI 4105B)
4.6 (69 items)
Limited Time Sale$58.66 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210913846 | Release Date | 2026/04/04 | List Price | $39.10 | Model Number | 210913846 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
RUOSHUI 4105A /4105B earth resistance meters grounding 4105A Ground resistance Range 0.1Ω~2000 Ω Ground current ( AC current) 200V resolution 0.1V 4105B Ground resistance Range 0.1Ω~1000 Ω Ground voltage 0V~1000V/ resolution ±(2%+5) Products Description 4105A/B Grounding Resistance Meter, as a professional instrument for measurement of grounding resistance of electrical equipment, is made by improving the circuit, structure and technology of traditional ground resistance meter. With a beautiful and practical fashion style, this meter will provide more complete function, higher accuracy and more convenient operation. Thanks to thedust-and-moisture proof structure, this meter is better suited to field operation. It is designed to measure the grounding resistance of grounding systems of a variety of power systems, electrical equipment and lightning protection equipment, and also to measure AC voltage. Packing: 1. Open-case Inspection 2. Grounding resistance meter 1 set 3. Canvas bag 1 Pcs 4. Ground drill rod 2 Pcs 5. Auxiliary testing wire 1 set (including: a piece of 15-meter red wire, 10-meter yellow and 5-meter green wire) 5. Simple testing wire 1 set (including: a piece of 1.6-meter red wire and 1.6-meter green wire) 6. alkaline battery (LR 6 AA 1.5V) 8Pcs 7. Instruction manual 1 copy Strap 1 piece General features (1) Display: 84.8 × 59.8mm window-type LCD display; Maximum displayed value "1999". (2) Over-range indication: the first digit is "1" when the upper limit is exceeded. (3) Power supply: 5# alkaline battery LR6 (1.5V) x 8 (can be connected to optional adapter); under-voltage indication function isprovided. (4) Overall dimensions: 175（L）×110(W) ×70（D）mm (5)Weight: about 680g (including batteries).
- 4105A Ground resistance Range 0.1Ω~2000 Ω Ground current ( AC current) 200V resolution 0.1V
- 4105B Ground resistance Range 0.1Ω~1000 Ω Ground voltage 0V~1000V/ resolution ±(2%+5)
- Full-featured, high accuracy, convenient and reliable operation
- Dustproof moisture-proof structure, better suited to field use
- Measure lightning protection equipment grounding system grounding resistance value
| Color | Orange |
|---|---|
| Model | EO-RUOSHUI 4105B |
| Brand Name | RuoShui |
| Style Name | Earth Resistance Ground Tester |
| Unit Count | 1.0 Count |
| Item Weight | 1 Kilograms |
| Manufacturer | Xi'an Beicheng Electronics Co.Ltd(RUOSHUI) |
| Power Source | Battery Powered |
| Item Dimensions | 7.87 x 5.91 x 7.09 inches |
| Specification Met | CE, RoHS, UL |
| Included Components | RUOSHUI 4105B |
| Upper Temperature Rating | 60 Degrees Celsius |
| EU Spare Part Availability Duration | 1 Years |
